Mechanical Seals

  1. EagleBurgmann Cartex Cartridge Seals - Versatile, Economical, and Efficient

    EagleBurgmann Cartex cartridge seals – economical, reliable and proven

    >60 % shorter installation time  |  >30 % more economical than component seals

    The cartridge principle - reliably cost-efficient

    EagleBurgmann Cartex cartridge seals are fully pre-assembled and precisely installed component seals incorporated in a cover and shaft sleeve. The seals are installed in pumps in a wide range of industries including chemicals, water supply, paper production, food processing and many other applications. Cartridge seals are easy to fit, and they keep your running costs down.

    Read more »
  2. Using Split Mechanical Seals - Splitex by EagleBurgmann

    What is a split mechanical seal?

    picture of splitex
    Splitex - A split seal by EagleBurgmann

    A mechanical seal is a device used to contain fluid within a vessel where a rotating shaft passes through housing, or sometimes where housing rotates around a shaft. These vessels are usually pumps, mixers, agitators, grinders, etc. The purpose of a mechanical seal is to allow the shaft to rotate freely without allowing large amounts of fluid to escape.

    How is a split mechanical seal different from a component or cartridge seal?

    A split seal comes in two separate pieces. Unlike ordinary cartridge mechanical seals, these two pieces can be installed or removed from around the shaft without disassembling the equipment. When joined, the sealing elements are mated to create a proper seal around the shaft.

    When should a split mechanical seal be used?

    Read more »
  3. Why are Mechanical Seals Still the Preferred Choice in the Process Industries?

    The challenges facing process industries have changed although they continue to pump fluids, some hazardous or toxic. Safety and reliability are still of prime importance. However, operators increase speeds, pressures, flow rates and even the severity of the fluid characteristics (temperature, concentration, viscosity, etc.) while processing many batch operations. For the operators of petroleum refineries, gas processing facilities and petrochemical and chemical plants, safety means controlling and preventing loss of, or exposure to, the pumped fluids. Reliability means pumps that operate efficiently and economically, with less required maintenance.

    picture of EagleBurgmann mechanical sealsA properly designed mechanical seal assures a pump operator of long-lasting, safe and reliable pump performance with a proven technology. Among multiple pieces of rotating equipment and a myriad of components, mechanical seals are proven to perform dependably under most types of operating conditions.

    Pumps & Seals—A Good Fit

    It is hard to believe that almost 30 years have passed since the mass promotion of sealless pump technology into the process industry. The new technology was promoted as the solution to all the issues and perceived limitations of mechanical seals. Some suggested that this alternative would eliminate the use of mechanical seals entirely.

    However, not long after this promotion, end users learned that mechanical seals could meet or exceed legislated leakage and containment requirements. Further, pump manufacturers supported the technology by providing updated seal chambers to replace the old compression packing “stuffing boxes.”

    Today’s seal chambers are designed specifically for mechanical seals, allowing for more robust technology in a cartridge platform, providing easier installation and creating an environment that allows the seals to function to their full potential.

    Design Advancements

    In the mid 1980s, new environmental regulations forced the industry not only to look at containment and emissions, but also at equipment reliability. The average mean time between repair (MTBR) for mechanical seals in a chemical plant was approximately 12 months. Today, the average MTBR is 30 months. Currently, the petroleum industry, subject to some of the most stringent emission levels, has an average MTBR of more than 60 months.

    Mechanical seals maintained their reputation by demonstrating the ability to meet and even exceed the requirements of best available control technology (BACT). Further, they did so while remaining an economical and energy efficient technology available to meet emission and environmental regulations.

    Computer programs allow seals to be modeled and prototyped prior to manufacturing to confirm how they will handle specific operating conditions before being installed in the field. Seal manufacturing design capabilities and the technology of seal face materials has progressed to the point that they can be developed for a one-to-one fit for a process application.

    Today’s computer modeling programs and technology allow the use of 3-D design review, finite element analysis (FEA), computational fluid dynamics (CFD), rigid body analysis and thermal imaging diagnostic programs that were not readily available in the past or were too costly for frequent use with earlier 2-D drafting. These advancements in modeling techniques have added to the design reliability of mechanical seals.

    These programs and technologies have led the way to the design of standard cartridge seals with much more robust components. These included the removal of springs and dynamic O-rings from the process fluid and made flexible stator technology the design of choice.

    Read more »
  4. Spring Types and Materials in Sealing Systems

    Springs are an integral part of all sealing systems. A simple air cylinder has O-rings to seal in the air, and the O-ring exhibits spring-like qualities to ensure a good seal over a broad temperature range.

    But what are the different types of springs and materials in sealing systems? And how do you choose the best for your application?

    image of metal spring types

    Metal Springs

    Metal springs, such as the Cantilever and Canted Coil spring, are used to energize polymers such as Teflon and ultra high molecular weight polyethylene (UHMW) to allow sealing in a wide range of temperatures. Selecting the correct spring material is critical to the life of the seal.

    Metal energized

    Read more »
  5. Gallagher Fluid Seals Announces e-Commerce Store

    Better and faster access to the seals you need to keep your production running.

    King of Prussia, PA. October 29, 2019 /News and Updates/ -- Gallagher Fluid Seals (GFS) is excited to announce the launch of its e-commerce store, providing a brand new experience to shop for seals.

    “It’s been a complete team effort,” says Chris Gallagher, CEO. “Our team has worked diligently over the past several months to prepare and deliver a state-of-the art e-commerce store for both new and returning customers.”

    As the world’s economy has evolved to an online platform, GFS felt seal buying should be easier. Gone are the days of calling in and ordering a replacement seal - or sending an RFQ. This new online experience allows greater and faster access to the seals you need to keep your facility up-and-running.

    “Maximizing the ease-of-purchase and visibility of fluid sealing products is imperative to the future of seal buying,

    Read more »
  6. How to Fight Leakage & Bearing Contamination with the Right Sealing Solution

    Consider mechanical seals, gland packed seals, and lip seals.

    The drive for operational efficiency, optimization of assets, and adherence to the International Standards Organization (ISO) 14001 Standard for environmental management systems and ISO-50001 standard for energy management systems must always be balanced against the bottom line.

    However, it is fair to say in some cases this can lead to short-sightedness when it comes to selecting sealing solutions, with lower cost at point-of-purchase taking precedence over total cost of ownership.

    Mechanical seals have been on the market for around 80 years, and while pump design has remained largely unaltered, sealing technology has evolved over time. This has resulted in advances in reliability, operational efficiency, and environmental sustainability.

    Traditional sealing options like gland packed seals and lip seals are traditional for a reason. These products are comparatively inexpensive when taking the purchase price into account, and work well in many applications. This article will take a look at the differences between mechanical seals, gland packed seals and lip seals.

    Excessive Wear

    Leakage, product loss and bearing contamination that leads to premature failure are three common issues with traditional seals.

    There is no reason why bearings should not last for their full predicted lifespan, which is typically calculated at roughly 15,250 operational hours. Leakage caused by inefficient sealing is the simple reason why they do not last. With research showing that water contamination of just 0.002 percent—a single drop—in a bearings chamber can reduce bearing life by almost half, it is easy to see why bearing failure is one of the most frequent causes of pump malfunction. The cost of regularly replacing damaged seals and bearings accumulates over time and can escalate if the pump shaft suffers wear damage and must be repaired or replaced.

    Another key cost, which is often overlooked, is the number of hours demanded to maintain, repair and replace these components.

    Read more »
  7. RoTechBooster Supplies Compressor Seals in the Power Plant

    What is the RoTechBooster by EagleBurgmann?

    RoTechBoosterThe RoTechBooster ensures abundant, reliable, and consistent seal gas flow, through fluctuating operating conditions; thus, clean and dry gas is supplied to the gas seal in every situation.

    Features of the RoTechBooster

    • Electric driven centrifugal design
    • Hermetically sealed
    • Delivers seal gas flow as defined by API
    • 24,000 hours of operation before required maintenance
    • Various models available, depending on requirements

    Advantages of the RoTechBooster

    • Simple to set-up, easy to operate
    • High reliability and availability
    • Unlimited continuous operation
    • Avoid seal failures
    • Low maintenance costs
    • Energy efficient
    • Eliminates the concern of unreliable external seal gas source


    RoTechBooster Case Study: Clean Gas Despite Fluctuating Operating Conditions

    The "Dock Sud“ combined power cycle plant in Buenos Aires, Argentina, is designed to adjust the power generation to the fluctuating electrical demand throughout all seasons. Managing the high demand during the summer months is particularly challenging, and the requirements for system component reliability are correspondingly high.

    dock-sud-power-station

    The power plant uses diesel engines and gas turbines to drive the generators. The diesel-driven generators run on a regular basis. The gas turbines are operated in start/stop mode so that they can respond quickly to high energy requirements or cope with peak loads.

    As a low-pressure gas supply for the plant was only available to use for the gas turbines, a MAN Diesel & Turbo four-stage geared compressor with dry gas seals provided the means to increase gas pressure to the appropriate level for them. There is one geared compressor for each of the two gas turbines on site. Another geared compressor is used as back-up. Due to the nature of the operation, the turbines stop and start frequently placing the geared compressors in a pressurized stand-by mode when electrical demand drops.

    Read more »
  8. Compressor Seals: The Espey™ WKA250ND

    Espey chamber seals have a modular design which means the seals can be composed using standard parts to meet individual application requirements. Espey chamber seals work with a very small operation gap between shaft and seal ring – leading to very low leakage – and are designed for dry-running and compensate radial and axial shaft deflections. Another advantage is that no sealing components which could generate additional shaft vibrations are actually fitted on the shaft. The seal rings are axially spring-loaded to prevent swinging up at pressure-less machine operation.

    Espey chamber seals are applied in several turbo machines: integral gear, screw and chiller compressors, steam turbines, and shut-off valves for power plants. The main industries in which it is implemented are oil and gas, refining, chemical and petrochemical industry, power plants, and plants for iron and steel production. A further industry field with several references and successes is carbon dioxide

    Read more »
  9. DiamondFace by EagleBurgmann - Innovative Sealing Technology

    What is DiamondFace Technology?

    DiamondFace is an innovative microcrystalline diamond coating for mechanical seals. It is extremely hard and offers high wear protection, excellent heat conductivity, maximum chemical resistance and low friction. The coating adhesion also exceeds all known practical requirements. This increases the service life of mechanical seals several times over, the maintenance intervals are extended accordingly and the life cycle costs are greatly reduced.

    DiamondFace Technology BenefitThe diamond thin-layer technology was developed in 2007 by EagleBurgmann together with the Fraunhofer Institute for Surface Engineering and Thin Films (IST), the Fraunhofer Institute for Ceramic Technologies and Systems (IKTS), Fraunhofer Institute for Mechanics of Materials (IWM), the Condias GmbH, and the Forschungszentrum Jülich. EagleBurgmann has established DiamondFace for mechanical seals as a series-produced product - the very first on the market.

    The technology behind it is a microcrystalline diamond layer up to 15 μm thick which is applied to the seal face under vacuum at temperatures of 2,000 °C (3,632 °F) by chemical vapor deposition (CVD). The properties of this diamond layer are where you benefit. Primarily from its extreme hardness and robustness.

    Increased Service Life of Mechanical Seals
    Mechanical seals are a factor that has a decisive effect on the cost-effectiveness of your operation because their wear determines the productivity of the entire system, whether it is a pump, agitator or compressor. What causes damage to the seal faces? One reason is dry running which is often unavoidable due to insufficient lubrication or when gas-lubricated seal faces get in contact. The resulting temperature rise causes the seal to wear. And ultimately results in system downtimes.

    EagleBurgmann has solved this problem which directly affects the success of your plant. Thanks to DiamondFace, the service life of mechanical seals is increased several times over, the maintenance intervals are extended accordingly and the life cycle costs are greatly reduced. The advantages for the operator are clear:

    Read more »
  10. The Complete Guide for Mechanical Seals & API 682 4th Edition Piping Plans

    Mechanical Seals & API 682 4th Edition

    A sealing system, consisting of a mechanical seal and an associated supply system that is balanced by individual applications, is the utmost guarantee for a reliable sealing point and uninterrupted pump service. The performance of the seal is greatly influenced by the environment around the seal faces, making the provision of suitable, clean fluids as well as a moderate temperature an essential topic.

    This guiding booklet provides a condensed overview of all piping plans established by the API 682 4th edition guidelines. Each illustrated piping plan is briefly described, and a recommendation that considers the media characteristics in terms of the relevant application and corresponding configurations is given to help you reliably select your sealing system. Furthermore, the content of this booklet has been enriched by providing clues – so-called ‘remarks and checkpoints’ – where

    Read more »
